TDG-U-SI-2C 2K Gap Filler dispensierbar

TDG-U-SI-2C is a 2-part dispensable low volatile LV silicone gap filler which is filled with thermally conductive fillers. After curing under heat the system remains elastic. It is characterised by very good dielectric and mechanic properties and is suited for compensating extreme tolerances and spaces at non-coplanar systems. Its thixotropic behaviour allows for a definite placement and cure-in-place. It has a natural low level tack that enhances a good thermal contact. Due to its negligible and controlled volatile content it is suited for environments where volatile silicones and paint wetting impairment are critical.




PROPRIÉTÉS

  • Dispensable 2-part silicone
  • Low volatile siloxane content (LV)
  • No paint wetting impairment
  • Thermal conductivity: 3.6 W/mK
  • Remains elastic after polymerisation
  • Zero stress on components
  • Heat accelerated curing
  • Shock absorbing

DISPONIBILITÉ

  • Cartridges 2 x 25 ml / 2 x 100 ml /
    2 x 200 ml / 2 x 600 ml
  • Pail 2 x 25 kg / 2 x 35 kg
  • On request

EXEMPLES D'APPLICATION

Thermal link of:

  • FPBGA
  • Capacitors
  • Heat Pipes
  • BGA

For use in Automotive applications / Telecommunication / Multimedia / Industrial PCs

OVERVIEW

PropertyUnitA-KomponenteB-Komponente
MaterialSilikonSilikon
ColourLight blueWeiss
Dichte @ 25 °C (gemischt)g/cm³2,852,85
MischungsverhältnisGew. oder Vol.1 : 11 : 1
HardnessShore 003838
Viskosität (Brookfield @ 10 rpm, 25 °C)Pas220190
Viskosität (gemischt (Brookfield @ 10 rpm, 25 °C))Pas260260
Topfzeit @ 25 °C und 65 % RH (Zeit bis doppelte Viskosität)Minuten> 100> 100
Curing Time @ 25 °C / 100 °C<15 h / 15-30 min<15 h / 15-30 min
Shelf Life (from Date of Manufacturing, unopened, @ < 35 °C)Months66
Outgasing TML/CVCM/WVR %0.07 / 0.02 / 0.040.07 / 0.02 / 0.04
No Paint Wetting Impairment Substances (PWIS)1YesYes
UL FlammabilityUL 94VOVO
RoHS Conformity2015 / 863 / EUYesYes
Technisch
Thermal Conductivity2W/mK3,63,6
Operating Temperature Range°C- 50 bis + 150- 50 bis + 150
Dielectric StrengthkV/mm> 10> 10
Volume ResistivityOhm-cm> 1 x 1010> 1 x 1010
