TGR-J-NS
CONTACT
Téléchargements TGR-J-NS Data Sheet
Commande d’échantillonnage
TGR-J-NS is high performing silicone-free thermal grease based on an ester oil matrix. It is ideal for use in applications where a very good and highly reliable thermal transfer must be achieved. Due to the specific formulation and filling with ceramic particles the material has a high thermal conductivity. By its use the thermal contact is maximised, hence the total thermal resistance is minimised.
PROPRIÉTÉS
- Thermal conductivity: 2.0 W/mK
- Silicone-free
- Dispensable
- Almost zero pressure at assembly
- Dielectric strength
- Operating temperature range: -40 to 150°C
DISPONIBILITÉ
- Syringes 70 ml
- Jars 1 kg
EXEMPLES D'APPLICATION
Thermal link of:
- LED Boards
- Power modules
- RDRAMs memory modules
- Flip Chips, DSPs , BGAs, PPGAs
For use in Automotive applications / Power electronics / Light technology / Industrial PCs
OVERVIEW
| Property | Unit | TGR-J-NS |
|---|---|---|
| Material | Keramik gefüllte Wärmeleitpaste | |
| Colour | Weiss | |
| Density | g / cm³ | 3,1 |
| Viskosität (Brookfield @ 10 rpm, 25 °C) | Pas | 170 |
| RoHS Conformity | 2015 / 863 / EU | Yes |
| Thermal | ||
| Thermal Conductivity | W/mK | 2,0 |
| Operating Temperature Range | °C | - 40 bis + 150 |
| Storage Temperature | °C | < 35 °C |
| Shelf Life (from Date of Manufacturing, unopened) | Months @ RT | 12 |
| Electric | ||
| Dielectric Strength | kV / mm | 5,0 |
