TGL-U-NS
OVERVIEW
Property | Unit | TGL-U-NS |
---|---|---|
Material | Ceramic filled silicone-free compound | |
Colour | Grey | |
Density | g/cm3 | 2.9 |
Viscosity (@ 0,5 1/s) (@ 1,0 1/s) | Pas | 3,300 2,500 |
Shelf Life (unopened, dry storage conditions @ 5–30°C) | Months | 6 |
UL Flammability (Equivalent) | UL 94 | V0 |
RoHS Conformity | 2015 / 863 / EU | Yes |
Thermal | ||
Thermal Conductivity | W/mK | 4.0 |
Operating Temperature Range | °C | - 40 to + 125 |
Electric | ||
Dielectric Strength | kV / mm | 8 |
Volume Resistance | Ohm - cm | 1.0 x 109 |
Dielectric Constant | @ 500 MHz / @ 1 GHz | 8.98 / 8.88 |
